Especificação
Câmera
Sensor de imagem
1/2.8" Progressive Scan CMOS
Resolução máx.
1920 × 1080
Iluminação mínima
Color: 0.001 Lux @ (F1.0, AGC ON),0 Lux with light
Tempo do obturador
1/3 s to 1/100,000 s
Dia e noite
IR cut filter
Ajuste de Ângulo
Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°
Lentes
Tipo de lente
Fixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV
2.8 mm, horizontal FOV 106°, vertical FOV 56°, diagonal FOV 129°
4 mm, horizontal FOV 88°, vertical FOV 47°, diagonal FOV 103°
Montagem da lente
M12
Iris Type
Fixed
Abertura
F1.0
DORI
DORI
2.8 mm, D: 44 m, O: 17 m, R: 8 m, I: 4 m
4 mm, D: 53 m, O: 21 m, R: 10 m, I: 5 m
luminador
Tipo de luz suplementar
IR,White Light
Faixa de luz suplementar
Up to 30 m
Luz complementar inteligente
Yes
IR Wavelength
850 nm
Vídeo
Convencional
50 Hz: 25 fps (1920 × 1080, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 720)
Subfluxo
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
Compressão de vídeo
Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG
Taxa de bits de vídeo
32 Kbps to 8 Mbps
Tipo H.264
Baseline Profile,Main Profile,High Profile
Tipo H.265
Main Profile
Controle da taxa de bits
CBR,VBR
Região de interesse (ROI)
1 fixed region for main stream
Áudio
Tipo de áudio
Mono sound
Compressão de áudio
G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC
Taxa de bits de áudio
64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
Taxa de amostragem de áudio
8 kHz/16 kHz
Filtragem de ruído ambiente
Yes
Rede
Protocolos
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IPv4, IPv6, IGMP, UDP, QoS, FTP, SMTP, UPnP
Visualização ao vivo simultânea
Up to 6 channels
API
ONVIF (Profile S, Profile G, Profile T),ISAPI,SDK
Segurança
Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
Usuário/Host
Up to 32 users
3 user levels: administrator, operator, and user
Client
iVMS-4200,Hik-Connect
Navegador da web
Plug-in required live view: IE 10, IE 11,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Imagem
Image Settings
Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
Switch Dia/Noite
Day,Night,Auto,Schedule
Ampla Faixa Dinâmica (WDR)
Digital WDR
SNR
= 52 dB
Aprimoramento da imagem
BLC,HLC,3D DNR
Máscara de privacidade
4 programmable polygon privacy masks
Interface
Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
Armazenamento a bordo
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Microfone integrado
Yes,1 built-in microphone
Alto-falante embutido
1 built-in speaker,
Max. power consumption: 2 W, max. sound pressure level: 10 cm: 101 dB.
Reset Key
Yes
Evento
Eventos básicos
Motion detection (support alarm triggering by specified target types (person and vehicle)), video tampering alarm, exception
Linkage
Upload to memory card, upload to FTP, trigger recording,notify surveillance center,send email,trigger capture
Geral
Alimentação
12 VDC ± 25%, 0.50 A, max. 6.0 W,Ø5.5 mm coaxial power plug,reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max. 7.2 W
Material
Metal & Plastic
Dimensões
Ø110 mm × 93 mm (Ø4.33" × 3.66")
Dimensões do pacote
150 mm × 150 mm × 141 mm (5.91" × 5.91" × 5.55")
Peso
Approx. 400 g (0.9 lb.)
Com peso do pacote
Approx. 646 g (1.4 lb.)
Condições de armazenamento
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Condições de inicialização e operação
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Idioma
English, Ukrainian
Função geral
Heartbeat,mirror,flash log,password reset via email,password protection,anti-banding
Luz intermitente
/SRB model: Red and Blue Light
/SL model: White Light
Aprovação
EMC
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021
Segurança
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005
Ambiente
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
Proteção
IP67: IEC 60529-2013
