CARACTERÍSTICAS DE HARDWARE
Interface 1× SC/APC GPON Port
1× 10/100/1000 Mbps WAN/LAN Port
3× 10/100/1000 Mbps LAN Ports
1× FXS Port
1× USB 2.0 Port
Botão WPS/Wi-Fi Button
RESET Button
Power On/Off Button
Fonte de Alimentação Externa 12V/1.5A
Taxa de Dados Downstream Speeds: 2.488 Gbps (GPON)
Upstream Speeds: 1.244 Gbps (GPON)§
Antena 4 External Antennas
CARACTERÍSTICAS WIRELESS
Padrões Wireless IEEE 802.11a/n/ac/ax 5 GHz
IEEE 802.11b/g/n/ax 2.4 GHz
Frequência 2.4 GHz and 5 GHz
Taxa de Sinal AX1800
5 GHz: Up to 1201 Mbps (HE80)
2.4 GHz: Up to 574 Mbps (HE40)*
Potência de Transmissão CE:
<20 dBm (2.4 GHz)
<23 dBm (5 GHz)
Funções Wireless Enable/Disable Wireless Radio, WMM, Wireless Statistics
Segurança Wireless WPA/WPA2/WPA3 Encryptions
Multi-SSID 2× 5 GHz Multi-SSID
2× 2.4 GHz Multi-SSID
Agendamento Wireless Support 2.4 GHz and 5 GHz Wireless Schedule
Mesh Technology EasyMesh Compatible, and support 802.11k/v/r
CARACTERÍSTICAS DE SOFTWARE
QoS Hardware QoS, Flow Classification
Segurança NAT Firewall, Access Control, MAC/IP/URL Filtering, IP and MAC Address Binding, Defense “Denial of Service (DoS), SYNFlooding, Ping of Death"
Gerenciamento Local management: WebGUI, Aginet app (for end users)
Remote management: Aginet ACS, OMCI, TR-069/TR-369, TR-098, TR-181, TR-111,TR-143 for service providers
Aginet APP for end user (need to log in wtih TP-Link ID and bind your device to it)
Cloud management: TP-Link Aginet Unified Cloud (TAUC)
DHCP Server, Client, DHCP Client List, Address Reservation, DHCP Relay
Redirecionamento de Portas Virtual Server, Port Triggering, DMZ, ALG, UPnP
DNS Dinâmico DynDns, NO-IP
VPN Pass-Through PPTP, L2TP, IPSec Pass-through
Protocolos IPv4, IPv6
Funções Avançadas Parental Controls, Network Address Translation(NAT), Port Mapping(Grouping), Static Routing, DNS Relay, DDNS, IGMP V1/V2/V3
VPN Server PPTP VPN, IPSec VPN , OpenVPN
OUTROS
Conteúdo do Pacote WiFi6 GPON Router XX230v
RJ45 Ethernet Cable
Power Adapter
Quick Installation Guide
Requerimentos do Sistema Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser
Subscription with an internet service provider (for internet access)
Ambiente Operating Temperature: 0?–40? (32?–104?)
Storage Temperature: -40?–60? (-40?–140?)
Operating Humidity: 10%–90% non-condensing
Storage Humidity: 5%–90% non-condensing
